Danfoss HP22 22mm 2 Port Motorised Valve Shoe Type 087N6609
The Danfoss 2 port motorised valve can easily connect to 22mm copper pipes.
Read more- Shoe type valve
- Includes interchangeable actuator
- Compatible with standard copper and iron pipe systems
- SPST switch
- Flow coefficient of 8.2 metre per cube per hour
- IP40 rated
This product will be available soon, please contact us for more information on this product.
Description
The Danfoss 2 port motorised valve can easily connect to 22mm copper pipes. Designed for use in both residential and commercial heating systems, its main function is to effectively stop and regulate the flow of water. Equipped with an external compression shoe type valve, it has a flow coefficient of 8.2 metres per cube per hour, with a maximum differential pressure of 1.0 bar and a maximum working pressure of 10 bar. This valve can also withstand a maximum operating temperature of 95C and has an IP40 rating for protection against dust and foreign objects.
- Shoe type valve
- Includes interchangeable actuator
- Compatible with standard copper and iron pipe systems
- SPST switch
- Flow coefficient of 8.2 metre per cube per hour
- IP40 rated
- 2 year warranty
- 28mm (inc 1”) - 1 lt/hr @ 0.7 bar differential pressure
- Opening time of up to 35 seconds and closing time of up to 20 seconds
* See Technical Attachments for precise parameters and conditions.
