Product code: H000015

Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW

Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW
Panasonic Aquarea T-CAP K Gen All in one Air Source Heat Pump Indoor Unit 9kW - 12kW

Introducing the new Aquarea T-CAP K Generation air-to-water heat pumps ...

Read more
  • Part of a split air source heat pump system
  • Suitable for replacing gas boilers or oil boilers
  • Combines stainless steel water tank and indoor unit in one
  • Compatible with Aquarea Smart Cloud (available separately)
  • Wi-Fi adapter included for smart connectivity
  • High energy savings and energy efficiency 'A' water pump with variable speed
Up to A+++
£4,930.66 excl. VAT
£5,916.79inc. VAT

Available in 1-2 days

Must be installed by an F-GAS Certified Installer. We require evidence of this before shipment. If you have any questions regarding these regulations, please contact us.

Description

Introducing the new Aquarea T-CAP K Generation air-to-water heat pumps. The extensive Aquarea product line offers tailored solutions to suit diverse lifestyles while delivering exceptional environmental performance, supporting our commitment to a carbon-free society through our GREEN IMPACT plan. Designed for both retrofits and new builds, Aquarea T-CAP is an ideal choice for replacing gas or oil boilers or integrating with underfloor heating, radiators, or fan coil units. It reliably maintains its heat pump output capacity even at outdoor temperatures as low as -20°C¹ without requiring an electrical booster heater. The indoor unit is thoughtfully designed to harmonize seamlessly with your interior. Finished in premium white, staying true to the Aquarea aesthetic, it features a sleek black band that houses the integrated controller for a modern and sophisticated look.

¹At a 35°C flow temperature.

Designed to work in tandem with an outdoor unit and various components. For more specific details, contact Oceanair for compatibility and suitability advice.

  • Part of a split air source heat pump system
  • Suitable for replacing gas boilers or oil boilers
  • Combines stainless steel water tank and indoor unit in one
  • Compatible with Aquarea Smart Cloud (available separately)
  • Wi-Fi adapter included for smart connectivity
  • High energy savings and energy efficiency 'A' water pump with variable speed
  • Environmentally friendly R32 refrigerant
  • Suitable for 9kw - 12kW heat pump systems
  • Suitable for new installations and high capacity homes
  • Compatible with underfloor heating Compatible with radiators
  • Award winning design Reduced maintenance requirements
  • Operates reliably in temperatures as low as -28°C
  • Supplies 60°C hot water even at an outdoor temperature of -10°C
  • Features a redesigned indoor unit Enhanced seamless connectivity integration Remote controller designed to complement the entire system seamlessly (Sold separately)



*See Technical Attachments for more precise parameters and conditions.

Specification

Brand Panasonic
Certifications Met EN14496
Colour White
Compatible with Compatible with various Panasonic Aquarea T-CAP Split Units from 9kW to 12kW, including WH-UXZ09KE5 Outdoor Unit. Contact Oceanair for more details.
Connection Type R1 1/4" Water Pipe Connector
COP* 5.03
EER* 3.11
Energy Rating Up to A+++
Fitting Requirements Must be installed by an F-GAS Certified Installer. We require evidence of this before shipment. If you have any questions regarding these regulations, please contact us.
Insulation Type U-Vacua™
Manufacturer Guarantee/ Manufacturer Warranty 3 Year Warranty (T's and C's Apply)
Manufacturer's Model No WH-ADC0912K6E5
Material Stainless Steel
Operating Ambient Temperature Range (Heating) Down to -28 °C
Operating Ambient Temperature Range (Hot Water) Up to 65 °C
Phrase Single Phase
Power Voltage Supply 240V, 50Hz
Product Depth 602mm
Product Height 1642mm
Product Width 599mm
Range Description Panasonic Aquarea T-CAP Air Source Heat Pumps - K Generation
Refrigerant Type R32
SCOP* 4.96
Sound Pressure Level 33 dBA
Suggested House Parameters Suitable for high energy consumption homes. Suitable for renovations.
Suitable for Renewable Energy Systems Suitable for Renewable Energy Systems
Suitable for Underfloor Heating Suitable for Underfloor Heating
System Suitability Suitable for Domestic Hot Water and Heating. Suitable for use with air to water heat pumps
System Type Domestic Heating and Cooling
Tank Capacity 185L
Type All in One Air to Water Heat Pump Indoor Unit
Wi-Fi Enabled Wi-Fi Enabled
* Efficiency Data Notes COP (A +7°C, W 35°C); Cooling capacity (A 35°C, W 7°C); Heating average climate (W 35°C / W 55°C). EER and COP calculation is based in accordance to EN14511.
